Enable container insight for EKS-Fargate in cloudwatch

In this article, we will demonstrate on how to implement Container Insights metrics using an (AWS Distro for OpenTelemetry) ADOT collector on an EKS Fargate cluster to visualize your cluster & container data at every layer of the performance stack in Amazon Cloudwatch. Presuming you have an EKS-Cluster with a fargate profile already up and running, if not follow the article to setup one. then it involves only the following things to achieve it -

- adot IAM service account

- adot-collector

- fargate profile for adot-collector

Create adot iamserviceaccount

eksctl create iamserviceaccount \
--cluster btcluster \
--region eu-west-2 \
--namespace fargate-container-insights \
--name adot-collector \
--attach-policy-arn arn:aws:iam::aws:policy/CloudWatchAgentServerPolicy \
--override-existing-serviceaccounts \
--approve

in-case of deleting iamserviceacount

eksctl delete iamserviceaccount --cluster btcluster --name adot-collector -n fargate-container-insights

Deploy Adot-collector

wget https://github.com/punitporwal07/kubernetes/blob/master/monitoring/cloudwatch-insight/eks-fargate-container-insights.yaml

kubectl apply -f eks-fargate-container-insights.yaml

Create compute fargate profile for the adot-collector pod that comes with statefulset

eksctl create fargateprofile --name adot-collector --cluster btcluster -n fargate-container-insights

Navigate to AWS cloudwatch

services > cloudWatch > logs > log groups & search for insight

services > cloudWatch > insights > Container insights > resources

services > cloudWatch > insights > Container insights > container map

Some helpful commands

to scale down statefulset -

kubectl -n fargate-container-insights patch statefulset.apps/adot-collector -p '{"spec": {"template": {"spec": {"nodeSelector": {"non-existing": "true"}}}}}'

to scale up statefulset -

kubectl -n fargate-container-insights patch statefulset.apps/adot-collector --type json -p='[{"op": "remove", "path": "/spec/template/spec/nodeSelector/non-existing"}]'

ref - https://aws.amazon.com/premiumsupport/knowledge-center/cloudwatch-container-insights-eks-fargate/

RBACs in Kubernetes

Security should be our top priority. In Kubernetes, role-based access control is used to grant users access to API resources. RBAC is a security design that restricts access to Kubernetes resources based on the roles.

There are two ways we can restrict and add RBAC policies

1. Namespace-wide RBAC policies

defining manifests to implement RBAC policies at the namespace level

with the above example, you have restricted the access to a specific namespace(myapp) for a specific application(Istio) linked with a serviceAccount deployed in the myapp namespace, but if you wish to access the resource of another namespace say myapp2 you will get a 403 forbidden error.

2. Cluster-wide RBAC policies

ClusterRoles are similar to Roles however when assigned to a ServiceAccount can give cluster-wide permissions to access other resources in it.

defining manifests to implement RBAC policies at cluster-wide level

with the above example, we have implemented clusterRoles to a ServiceAccount to access resources at a cluster-wide level.

if the user tries to access another namespace or system namespace like (kube-system). definitely, it will throw a forbidden error because when we create this user/SA only have access to myapp & myapp2 namespace. Usually, developers no need access to the system namespace (kube-system).

Minikube - lightweight Kubernetes cluster

 Launching Kubernetes as a single node cluster locally

Minikube is the tool that allows you to launch K8S locally. Minikubes runs as a single-node-k8s-cluster inside a VM at your local, before you install kubectl do as below

 # Install minikube on Ubuntu

 # setup minikube using the script here -
   https://github.com/punitporwal07/minikube/blob/master/install-minikube-v2.sh

 # Install minikube on Linux
 # use this script to launch k8s-cluster on local and interact with Minikube install-minikube.sh
 $ git clone https://github.com/punitporwal07/minikube.git

 $ cd minikube
 $ chmod +x install-minikube.sh

 Now add your localuser as sudo-user, with root do the following -

 $ vi /etc/sudoers

   next to root ALL=(ALL) add as below for your user

   localuser ALL=(ALL) NOPASSWD:ALL

 $ su - localuser

 $ ./install-minikube.sh

basic minikube command

Function	Command
verify kubectl to talk to the cluster	kubectl config current-context ( should return minikube)
to start/stop cluster with resources	minikube start/stop  minikube start --cpus 6 --memory 8192
to delete note	minikube delete
start version-specific Kube node	minikube start --vm-driver=none --kubernetes-version="v1.20.0"
check node info	kubectl get nodes
kubernetes cluster-info	kubectl cluster-info
kubectl binary for Windows	kubectl.exe
minikube 64-bit installer	minikube-installer.exe

Launch EKS using eksctl in AWS

There are ways to exploit kubernetes to deploy the application. Perhaps when you are running out of resources to manage the kubernetes cluster you have an option to use the kubernetes service backed by a cloud provider that will take all the burden of managing the cluster on your behalf known as managed kubernetes service and when deployed on AWS called as Elastic Kubernetes Service.

In this article, I will call kubernetes+cluster=Kluster

1. To start with EKS you need to fulfil the following prerequisites.

    a. Own an AWS account (free tier will work)
    b. Create a VPC (virtual private space that will not affect other components in your acc)
    c. Create an IAM role with the security group. ( AWS user with a list of permissions to setup EKS)

2. To create a Kluster Control Plane you should have the following in place

    a. Kluster name, kubernetes version
    b. Region & VPC for kluster
    c. Security for kluster

3. Create worker nodes for your kluster ( set of EC2 instances)

    a. Create as a Node Group ( autoscaling enabled)
    b. Choose kluster it will attach to
    c. Define security group, select instance type, resources
    d. Define max & min number of nodes.

Then we use kubectl from our local to access kluster and deploy resources on it

Alternatively, we can use eksctl an official CLI tool for creating & managing kluster on EKS that is written in go & uses cloudFormation to set up EKS fast & effectively.

  # below command will do all the job mentioned above at
    runtime and will be using default values

  $ eksctl create cluster


Let's demonstrate how this will be done

first, install eksctl to use this utility follow the instruction here

NOTE: Before creating a cluster using eksctl util it is important to connect and authenticate to your AWS account, follow the instructions to connect

 $ aws configure // that will prompt you to provide

   AWS Access Key ID [*********SIXH]: AKIAUYDUMMY73NXMF
   AWS Secret Access Key [*********6oB6]: mbJBDUMMYfm09oqONa
   Default region name [ap-south-1]:
   Default output format [None]: json

   // this user will be able to access the cluster

once this is done start creating your cluster using eksctl

 $ eksctl create cluster \
   --name first-kluster \
   --version 1.20 \
   --region ap-south-1 \
   --nodegroup-name linux-worker-nodes \
   --node-type t2.micro \
   --nodes 2

Alternatively, you can create a node group by running the following command

 # create public node group

 $ eksctl create nodegroup –cluster=first-kluster \
   --region=ap-south-1 \
   --name=node-group-name \
   --node-type=t2.micro \
   -–nodes=2 \
   -–nodes-min=2 \
   -–nodes-max=4 \
   -–node-volume-size=20 \
   -–ssh-access \
   -–ssh-public-key=ssh-key-pair-name \
   -–managed \
   -–asg-access \
   -–external-dns-access \
   -–full-ecr-access \
   -–appmesh-access \
   -–alb-ingress-access

 # List NodeGroups
 $ eksctl get nodegroup –cluster=<clusterName>

 # List Nodes
 $ kubectl get nodes -o wide

 # if fails to list nodes -

   export KUBECONFIG=$LOCATIONofKUBECONFIG/kubeconfig_myEKSCluster
   export AWS_DEFAULT_REGION=eu-west-2
   export AWS_DEFAULT_PROFILE=dev

 $ aws eks update-kubeconfig --name myEKSCluster --region=eu-west-2

 Added new context arn:aws:eks:eu-west-2:295XXXX62576:cluster/myEKSCluster to $PWD/kubeconfig_myEKSCluster

eksctl does provide an option to create a customized cluster using a yaml file

 apiVersion: eksctl.io/v1alpha5
 kind: ClusterConfig

 metadata:
   name: first-kluster
   region: ap-south-1

 nodeGroups:
   - name: linux-worker-nodes-1
     instanceType: t2.micro
     desiredCapacity: 5
   - name: linux-worker-nodes-2
     instanceType: m5.large
     desiredCapacity: 2

 $ eksctl create cluster -f cluster.yaml

this will automatically create and assign VPC/subnet

once this is done you will be able to see your cluster in AWS console and same time can see its nodes in CLI using kubectl get nodes

once the cluster is created you will be able to find its credential file under ~/.kube/config which further can be used with different tools and products for integration and monitoring purpose of your kluster

  # In-order to delete a cluster

  $ eksctl delete cluster --name first-kluster


--

Kubernetes cheatsheet

Kubernetes is an orchestration framework for containers that give you portability for managing containerized workloads and services in form of pods, there are two types of CLI commands -

Imperative - imperative commands are one-liners commands.
Declarative - declarative has some definition of objects in a file that a developer can refer it again.
There are different CLI tools that allow you to run commands against the Kubernetes cluster some of which I attempted to collect and put together as below.

Function	Command
kubectl auto-complete	echo "source <(kubectl completion bash)" >> ~/.bashrc
Initialize cluster  verify cluster-info verify kluster + components reset cluster delete tunl0 iface delete pods forcefully deregister a node from the cluster (Unscheduling enabled) Scheduling enabled add a taint to a node remove a taint from a node label a node	kubeadm init --apiserver-advertise-address=MASTERIP --pod-network-cidr=192.168.0.0/16 kubectl cluster-info --minify kubectl version --short && \ kubectl get componentstatus && \ kubectl get nodes --show-labels && \ kubectl cluster-info kubeadm reset -f && rm -rf /etc/kubernetes/ modprobe -r ipip kubectl delete pods --all -n kube-system --grace-period=0 --force kubectl cordon nodeName kubectl drain nodeName  kubectl drain nodeName --ignore-daemonsets --delete-local-data --force kubectl delete node nodeName kubectl uncordon nodeName kubectl taint nodes node01 key1=value1:NoSchedule kubectl taint nodes node01 key1=value1:NoSchedule- kubectl label nodes node01 key=value
setting namespace preference validate current namespace list everything in the cluster	kubectl config set-context --current --namespace=<namespace-name> kubectl config view --minify | grep namespace kubectl get all --all-namespaces
investigate any object investigate kubelet service	kubectl describe node/deployment/svc <objectName> sudo journalctl -u kubelet
exposing deployment as a service patch a svc from ClusterIP to NP port forwarding in svc scaling your deployment use service deployed in other ns	kubectl expose deploy/web --type=NodePort --name=my-svc  kubectl expose deploy/web --port=9443 --target-port=61002 --name=mysvc --type=LoadBalancer kubectl patch svc argocd-server -n argocd -p '{"spec": {"type": "NodePort"}}'  kubectl port-forward svc/my-service -n myNamespace 8080:443 kubectl proxy --port=61000 --address=0.0.0.0 --accept-hosts '.*' & kubectl scale --current-replicas=3 --replicas=4 deployment/my-deployment kubectl scale deployment/my-deployment --replicas=2 -n my-namespace Dns name: <service-name>.<namespace>.svc.cluster.<domain>
all possible attributes of an obj wide details of running pods delete a pod forcefully delete bulk rsrc from a namespace	kubectl explain pod --recursive kubectl get pods -o wide kubectl delete pod mypodName --grace-period=0 --force --namespace myNamespace kubectl delete --all po/podName -n my-namespace
open a bash terminal in a pod  run shell command	kubectl exec -it podName -- bash kubectl exec -it podName -- cat /etc/hosts
create a yaml manifest,  without sending it to the cluster apply a folder of yaml files validate a yaml	kubectl create deploy web --image=nginx --dry-run -o yaml > web.yaml [Imperative way] kubectl apply -R -f . kubectl create --dry-run=client --validate -f file.yaml
create a deployment edit deployment web runtime autoscale deployment  rolling update validate the rollout undo the rollout	kubectl create deploy --image=nginx web --replicas=3 kubectl edit deploy/web kubectl autoscale deploy/web --min=2 --max=5 --cpu-percent=10 kubectl set image deploy/web web=regustry/web:2.0 kubectl rollout status deploy/web kubectl rollout undo deploy/web
passing configmap string passing cm as a properties file   query health check endpoint	kubectl create configmap my-config --from-literal=MESSAGE="hello from configmap” kubectl create cm my-config --from-file=my.properties curl -L http://localhost:8080/healthz
dump logs	kubectl logs podName  kubectl logs podName -c containerName

run kubectl against pods using xargs fetch 1st colmn from o/p of multi pods       refine o/p with specific value

kubectl get pods -o name | xargs -I{} kubectl exec {} -- command  kubectl get pods -n ns | grep -v NAME | sed 's/\|/ /'|awk '{print $1}' kubectl get pods -n ns | grep -v NAME | awk '{print $1}' | cut -c8-14

Calculate max pods in an EC2 instance type

curl -O https://gist.githubusercontent.com/punitporwal07/4dccce3e51503b8fc786d754e64fbe6f/raw/0e4d130db82ee953ce9f93366a35b803cac39faa/max-pods-calculator.sh chmod +x max-pods-calculator.sh aws configure ./max-pods-calculator.sh --instance-type m5.large --cni-version 1.9.0-eksbuild.1

Different api versions to use in your manifest file

according to kubernetes : The API server exposes an HTTP API that lets end users, different parts of your cluster, and external components communicate with one another. The Kubernetes API lets you query and manipulate the state of objects in the Kubernetes API (for example: Pods, Namespaces, ConfigMaps, and Events)

                                  APIs are gateway to your kubernetes cluster

Kind	apiVersion
CertificateSigningRequest	certificates.k8s.io/v1beta1
ClusterRoleBinding	rbac.authorization.k8s.io/v1
ClusterRole	rbac.authorization.k8s.io/v1
ComponentStatus	v1
ConfigMap	v1
ControllerRevision	apps/v1
CronJob	batch/v1beta1
DaemonSet	extensions/v1beta1
Deployment	extensions/v1beta1
Endpoints	v1
Event	v1
HorizontalPodAutoscaler	autoscaling/v1
Ingress	extensions/v1beta1
Job	batch/v1
LimitRange	v1
Namespace	v1
NetworkPolicy	extensions/v1beta1
Node	v1
PersistentVolumeClaim	v1
PersistentVolume	v1
PodDisruptionBudget	policy/v1beta1
Pod	v1
PodSecurityPolicy	extensions/v1beta1
PodTemplate	v1
ReplicaSet	extensions/v1beta1
ReplicationController	v1
ResourceQuota	v1
RoleBinding	rbac.authorization.k8s.io/v1
Role	rbac.authorization.k8s.io/v1
Secret	v1
ServiceAccount	v1
Service	v1
StatefulSet	apps/v1

alpha

API versions with ‘alpha’ in their name are early candidates for new functionality coming into Kubernetes. These may contain bugs and are not guaranteed to work in the future.

beta

‘beta’ in the API version name means that testing has progressed past alpha level, and that the feature will eventually be included in Kubernetes. Although the way it works might change, and the way objects are defined may change completely, the feature itself is highly likely to make it into Kubernetes in some form.

stable

Those do not contain ‘alpha’ or ‘beta’ in their name. They are safe to use.

reference

PROBES - Health check mechanism of application running inside Pod's container in Kubernetes

Kubernetes provides health checking mechanism to verify if a container inside a pod is working or not using PROBE.

Kubernetes gives two types of health checks performed by the kubelet.

Liveness probe

k8s checks the status of the container via liveness probe.

If liveness Probe fails, then the container is subjected to its restart policy.

Readiness Probe

Readiness probe checks whether your application is ready to serve the requests.

If readiness probe fails, the pod's IP is removed from the endpoint list of the service.

we can define liveness probe in three types of actions that kubelet performs on a pod:

• Executes a command inside the container
• Checks for a state of a particular port on the container
• Performs a GET request on container's IP

# Define a liveness command
livenessProbe:
  exec:
    command:
    - sh
    - /tmp/status.sh; sleep 10; rm /tmp/status.sh; sleep 600
  initialDelaySeconds: 10
  periodSeconds: 5

# Define a liveness HTTP request
livenessProbe:
  httpGet:
    path: /healthz
    port: 10254
  initialDelaySeconds: 5
  periodSeconds: 3
# Define a TCP liveness probe
livenessProbe:
  tcpSocket:
    port: 8080
  initialDelaySeconds: 15
  periodSeconds: 20

Readiness probes are configured similarly to liveness probes.
The only difference is that you use the readinessProbe field
instead of the livenessProbe field.

# Define readiness probe
readinessProbe:
  exec:
    command:
    - sh
    - /tmp/status_check.sh
  initialDelaySeconds: 5
  periodSeconds: 5

Configure Probes

Probes have a number of fields that one can use more precisely to control the behavior of liveness and readiness checks

initialDelaySeconds: Number of seconds after the container starts before liveness or readiness probes are initiated.

Defaults to 0 seconds. Minimum value is 0.

periodSeconds: How often (in seconds) to perform the probe.

Default to 10 seconds. Minimum value is 1.

timeoutSeconds: Number of seconds after which the probe times out.

Defaults to 1 second. Minimum value is 1.

successThreshold: Minimum consecutive successes for the probe to be considered successful after having failed.

Defaults to 1. Must be 1 for liveness. Minimum value is 1.

failureThreshold: Minimum consecutive fails for the probe to be considered restarting the container. In case of readiness probe, the Pod will be marked Unready.

Defaults to 3. Minimum value is 1.

# example of Nginx deployment
apiVersion: apps/v1
kind: Deployment
metadata:
  name: app1
  labels:
    app: webserver
spec:
  replicas: 1
  template:
    metadata:
      labels:
        app: webserver
    spec:
      containers:
        - name: app1
          image: punitporwal07/apache4ingress:1.0
          imagePullPolicy: Always
          ports:
            - containerPort: 80
          livenessProbe:
            httpGet:
              path: /
              port: 80
            initialDelaySeconds: 5
            periodSeconds: 3
          readinessProbe:
            httpGet:
              path: /
              port: 80
            initialDelaySeconds: 5
            periodSeconds: 3

httpGet have additional fields that can be set

path: Path to access on the HTTP server.

port: Name or number of the port to access the container. The number must be in the range of 1 to 65535.

host: Hostname to connect to, defaults to the pod IP. You probably want to set "Host" in httpHeaders instead.

httpHeaders: Custom headers to set in the request. HTTP allows repeated headers.

scheme: Scheme to use for connecting to the host (HTTP or HTTPS). Defaults to HTTP

keep probing!
